Dell PowerEdge T30

T30 Mini Server

This server is perfect for storing and sharing information data and applications can be consolidated on this one server from multiple devices. The T30 uses Intel Xeon E3-1225 v5 processor family and has 4 DIMM slots for large DDR4 memory capacity. There are 6 internal hard drives and 4 PCL/PCLe slots for a lot of storage space. This server will be a perfect addition to your home or office space.


Specifications

Processor: 1 processor from the following product families:

  • Intel Xeon processor E3-1225 v5
  • Intel Pentium G4400

Cache:

  • 8MB cache on Intel Xeon E3-1225 v5
  • 3MB on Pentium G4400

Chipset: Intel C236

Memory:

  • Architecture: 4 DIMM slots
  • Maximum RAM: up to 64GB DDR4 2133MT/s

I/O Slots: 4 slots:

  • 1 PCIe x16 3.0
  • 1 PCIe x16 3.0 (x4 speed)
  • 1 PCIe x4 3.0
  • 1 PCI

Raid Controllers: Software RAID: Intel Rapid Storage Controller 12.0 (supports SATA 6Gb/s or SATA 3Gb/s)

Drive Bays: Up to 6 total SATA HDDs (4 x 3.5” SATA HDD + 2 additional 2.5” SATA HDD (w/ expansion kit and optional controller card)

Embedded Nic: Intel I219-LM GbE LAN 10/100/1000 1-port

Power Supply: 290W cabled PSU
