Dell Precision 7920 AutoCAD Workstation 2x Gold 5122 8 Cores 16 Threads 3.6Ghz 256GB 500GB NVMe Quadro M5000 Win 10 Pro

AutoCAD workstations are designed for optimal performance to give you the power you need to efficiently complete your work. Recommended for performance: Processors Speed – Faster the better. Recommend 3Ghz or higher. Processor Cores – Higher core counts are only utilized when rendering. We recommend 4 cores or more. Memory (RAM) – 20x of your compacted central project file is a good rule of thumb. Recommend 16GB or higher. Storage – Faster drives will improve overall workstation responsiveness. Its recommended to use a SSD for the Operating system and program loading, and HDD for file storage. Graphic Card (GPU) - Dedicated video cards supporting DirectX 11 or later are strongly recommended. Nvidia Quadro are supported and certified by AutoDesk. This workstation is certified to work with AutoCAD

Processor: Dual Intel Xeon Gold 5122 Quad Core 3.6Ghz Processors 8 Cores, 16 Virtual Cores in Hyperthreading Mode! (Additional processor configurations available)

Memory: 256GB DDR4-2666 Memory. Supports up to 1536GB of total memory, Six channel memory up to 2666MHz DDR4 ECC memory with dual CPUs, 24 DIMM Slots (12 DIMMs per CPU).

PCIe Solid State Drive: 500GB NVMe M.2 SSD with PCIe Adapter Card

Drive Bays: (4) Hotswap Bays which support 3.5" or 2.5" drives. Can support up to 6 additional drives with optional 5.25" and rear flexbay added, contact us for a qoute.

Raid Controller: Onboard SATA Controller, Raid 0,1,5,10

Graphics: Nvidia Quadro M5000 8GB GDDR5 Graphic Card, DirectX 12 - 1 DVDI, 4 DisplayPort - Support up to 4 active monitors (Certified Hardware for AutoCAD 2019)

Operating System: Windows 10 Professional

Software: AutoCAD Software is not included

Power Supply: 1400W(input voltage 100VAC - 240VAC) –90% efficient (80PLUS Gold Certified) Externally accessible/removable/lockable

Optical: DVDRW Drive

Networking: Intel i219 & i210 Gigabit Ethernet controllers with Intel Remote Wake UP, PXE and Jumbo frames support

Slots: All slots PCIe Gen 3: (2) PCIe x16, (2) additional x16 slots with 2nd CPU; (1) PCIe x8 open ended, (1) x16 wired as x 4, (1) x16 wired as x1

Front Ports: (2) USB 3.1 Gen 1 Type A, (2) USB 3.1 Type C, (1) Universal Audio Jack, Up to 4 x 4 PCIe slots in PCIe enabled chassis for M.2 and U.2 (future) PCIe SSDs

Rear Ports: (6) USB 3.1 Gen 1 Type A, (1) Serial, (2) RJ45 Network, (2) PS2, (1) Audio Line out, (1) Audio Line in/Microphone

Internal Ports: (1) USB 2.0,(1) 2 x 5 USB 2.0 header. (requires 3rd party splitter cable to support 2 x USB 2.0 Type A ports), (8) SATA @6Gb/s plus 1 SATA for optical

Peripherals: Power Cable Included. Mouse, Keyboard, and Video Cable Not Included.

Condition: Seller refurbished unit may have minor scratches and scuffs

*Systems are built to order and fully customizable. Please contact us directly to customize a system for you - REQUEST A QUOTE Please note that a stock photo is used and unit may differ depending on configuration.
